Maximum weaving outer diameter

Φ14mm

Number of woven threads/per spindle

Φ0.25mm(1-7条)   Φ0.15mm(1-13条)    Φ0.12mm(2-13条)
Φ0.08mm(3-13条)  Φ0.05mm(4-13条)

Spindle speed

180RPM （The actual speed is determined by the weaving wire and pitch, and the factory value is set at 150RPM, which is our recommended general optimal speed.)

Maximum production speed

570m/h   (According to the maximum production pitch X maximum speed calculation, the actual speed is determined by the weaving wire and pitch)

Range of pitch adjustment

Shift gears between 5.35-65.3mm with stepwise adjustment

Main motor

380V    1.1KW

noise

≤76db

Wire reel specifications

Φ800mm*600mm

Skeleton specifications

Φ66mm*82.5mm

Axis hole for cable reel

Φ＞38mm≤80mm

Total weight of the machine

≈500Kg

Standard
Equipment configuration

1. New easy to maintain circuit device 2. Pitch adjustment device
3. Variable frequency control device 4. Electronic monitoring disconnection device
5. Monitoring device for longitudinal wrapped metal strip breakage 6. Weaving wire tension adjustment device
7. Device for freely adjusting the wire width of the winding reel 8. Automatic stop device for weaving wire breakage
9. Automatic refueling device

Woven Silk Description

1. Woven wire can be made of soft copper wire, aluminum magnesium alloy wire, stainless steel wire, polyester wire, cotton wire, etc;
2. The elongation of soft copper wire shall not be less than 10-17%, and the elongation of aluminum magnesium alloy wire shall be 3-5%;
3. The elongation of stainless steel wire is between 38-45%; The tensile strength is 700-730MPA (measured in diameter of 0.20mm).

Special requirements remarks
